Description
PANDA 150W – ELECTRICAL SPECIFICATIONS
Maximum Power (Pmax): 150 W (+5%)
Maximum Power Voltage (Vmp): 18.56 V
Maximum Power Current (Imp): 8.06 A
Open Circuit Voltage (Voc): 23.8 V (+5%)
Short Circuit Current (Isc): 9.1 A (+5%)
Maximum Series Fuse: 15 A
Operating Temperature: (-40) – (+185) °F / (-40) – (+85) °C
Temperature Coefficient Isc (): 0.057 %/℃
Temperature Coefficient Voc (): -0.288 %/℃
Temperature Coefficient Pmax (): -0.423 %/℃
PANDA 150W – MECHANICAL DATA
Cell Type: 36 Apollo Cells (6×6)
Dimensions (mm / in): 1055 x 1005 x 2.2 , JB Height 14.8 / 41.53 x 39.5 x 0.09 , JB Height 0.58
Weight (kg / lb): 2.9 / 6.4 (±5%)
Max. Bending Diameter (mm): 1000 (±5)
Junction Box: Front Side, IP68 Rated
Connector Type: Original MC4-EVO2
Output Cables: 20cm / 4mm² (12AWG) Cross-Section
Backside Material: PET
Frame: Frameless Module
Class (IEC 61730-1:2016): Class II
Fire Class (UL 61730, UL790): C
Static Load Certification: 2400 Pa
PANDA 300W – ELECTRICAL SPECIFICATIONS
STC 1,000 W/sqm, (25 ±2)°C, AM
Maximum Power (Pmax): 300 W (+5%)
Maximum Power Voltage (Vmp): 38 V
Maximum Power Current (Imp): 7.88 A
Open Circuit Voltage (Voc): 47.5 V (+5%)
Short Circuit Current (Isc): 8.6 A (+5%)
Maximum Series Fuse: 15 A
Operating Temperature: (-40) – (+185) °F / (-40) – (+85) °C
Temperature Coefficient Isc (): 0.057 %/℃
Temperature Coefficient Voc (): -0.288 %/℃
Temperature Coefficient Pmax (): -0.423 %/℃
Maximum System Voltage: 1000 VDC
PANDA 300W – MECHANICAL DATA
Cell Type: 72Apollo Cells (6×12)
Dimensions (mm / in): 2020 x 1005 x 2.2 , JB Height 14.8 / 79.5 x 39.5 x 0.09 , JB Height 0.58
Weight (kg / lb): 5.8 / 12.7 (±5%)
Max. Bending Diameter (mm): 1000 (±5)
Junction Box: Front Side, IP68 Rated
Connector Type: Original MC4-EVO2
Output Cables: 120cm / 20cm / 4mm² (12AWG) Cross-Section
Backside Material: PET
Frame: Frameless Module
Class (IEC 61730-1:2016): Class II
Fire Class (UL 61730, UL790): C
Static Load Certification: 2400 Pa
